FAIRDALE Ridgemont Purple Rain in S/M & M/L – bicikl
The Ridgemont is a bit of an oddball bike that we think is both practical and enjoyable. When the bike path ends, the Ridgemont keeps going with 2.0″ wide 27.5″ tires and stable MX bars.
The laidback and rugged steel frame makes the bike both comfortable and strong. The hills are tamed by 8 easy-to-use gears that you pick with just one click of your thumb. Not a “normal” around town bike, nor a hardcore mountain bike, the Ridgemont is a bike that is simply fun to ride where ever you end up.
Gloss Black is available in Small/Medium and Medium/Large.
Purple Rain is available in Small/Medium and Medium/Large.
Sizing
Small/Medium: 5’2″ – 5’8″ height
Medium/Large: 5’6 – 6’0″ height
Sizing is approximate. Please consult with your local bike shop to assist with fit.
Specifications FAIRDALE Ridgemont Purple Rain in S/M & M/L – bicikl
Frame: 1020 Steel with 1-1/8” Integrated Head Tube
Fork: 1020 Steel 1-1/8” Steerer tube
Handlebar: Fairdale MX-4 Bar, 100% Chromoly
Stem: Sunday Freeze, Top-Load, 48mm Reach
Headset: FSA, Sealed Integrated, 45º/45º
Brake Lever: Aluminum
Brake: Aluminum V-Brakes
Grips: Fairdale Swan
Saddle: Fairdale Logo
Seat Post: 27.2mm Micro Adjust
Seat Clamp: 30mm Fairdale Clamp
Cranks: FSA Tempo 1X (S/M = 170mm, M/L = 175mm)
Chainwheel: Fairdale, 36T
BB Parts: FSA
Pedals: Odyssey Twisted PC
Rims: 36-Hole, Aluminum, Double Wall, Pinned Joint, Schrader Valve
Front Hub: 36H, 3/8” Axle , Aluminum Shell, Looseball
Rear Hub: 36H, 3/8” Axle, 7-Speed, Aluminum Shell, Looseball
Tires: Continental Double Fighter III, 27.5 x 2.0”
Chain: KMC Z8.1
Driver: 8-Speed, 13-34t
R. Shift Lever: SRAM X4 Trigger, 8-Speed
*R. Shift Lever Alternate: Microshift TS39-8R, 8-Speed
R. Derailleur: SRAM X4, Mid-cage, 8-Speed
*R. Derailleur Alternate: Microshift RD-M26CS, 8-Speed
Shift Cable: Fairdale
Geometry
| Size | S/M (57cm) | M/L (60cm) |
| Top Tube (Effective) | 575mm | 606mm |
| Top Tube (Actual) | 544mm | 581mm |
| Seat Tube (BB Center to TT Top) | 415mm | 500mm |
| Seat Tube (BB Center to TT Center) |
379mm | 464mm |
| Seat Tube Angle | 70° | 70° |
| Head Tube Length | 115mm | 160mm |
| Head Tube Angle | 69° | 69° |
| Chain Stay Length | 442mm | 442mm |
| Wheelbase | 1057mm | 1089mm |
| Standover | 734mm | 794mm |
| Stack | 516mm | 558mm |
| Reach | 387mm | 403mm |
| Fork Length | 399mm | 399mm |
| Fork Offset | 50mm | 50mm |
| BB Drop | 54mm | 54mm |
| Dropout Spacing | 135mm | 135mm |
| BB Type | Threaded English |
Threaded English |
| Seat Post | 27.2mm | 27.2mm |
| Seat Clamp | 30mm | 30mm |
| Approx. Max Tire Width | 56mm | 56mm |
| Wheel Size | 27.5″ | 27.5″ |
*Specs subject to change without notice.
